FriendlyElec

NanoPi NEO3 Plus- Compact and Powerful Single Board Computer

$25.50
Opens WhatsApp with this product and current options


NanoPi NEO3 Plus - Compact and Powerful Single Board Computer

SKU FELEC-NEOMBK256

NanoPi NEO3 Plus - Compact and Powerful Single Board Computer

The NanoPi NEO3 Plus is a compact single board computer designed for various applications. It features a powerful RK3588S SoC, making it suitable for both development and production environments.

Resources
Official documentation (Wiki):
FriendlyElec product page:

Specifications may vary by configuration. Contact us for project-specific options.

Specification Details
CPU Allwinner H3, Quad-core Cortex-A7 Up to 1.2GHz
DDR3 RAM 256MB/512MB
Connectivity 10/100M Ethernet
USB Host Type-A x 1, 2.54 mm pin x 2
MicroUSB OTG, for power input
Debug Serial Port 4Pin, 2.54 mm pitch pin header
Audio input/output Port 5Pin, 2.0mm pitch pin header
GPIO 2.54mm pitch 36pin. It includes UART, SPI, I2C, IO etc
Power Supply DC 5V/2A
PCB Dimension 40 x 40 mm
Working Temperature -20℃ to 70℃
Weight 14g(WITHOUT Pin-headers)
OS/Software u-boot, UbuntuCore and Android
Cooling Fanless
